可视化理解 Shamir's Secret Share 密钥共享算法的数学原理

Sharmir‘s Secret Share 算法是一种加密算法，在不受信任的网络中可以使用它来安全地分发私密信息。无密钥安全技术（生物识别数据、私钥等）使用 Sharmir‘s Secret Share 算法来确保个人数据的安全。Sharmir‘s Secret Share 算法是 1979 年著名密码学家阿迪·沙米尔（Adi Shamir）提出了一种新的 secret 共享方法。本文可视化理解 Sharmir's Share Secret 算法的方法源自 Evervault 工程师 David Nugent。

多项式描述

正如上面的视频中描绘的多项式，它是 3 次多项式，因为 x 的最大幂是 3。多项式适用于秘密共享，因为您可以给人们曲线上的一些点，而无需向他们透露多项式是什么。这意味着您可以共享点，但只有当他们有足够的点时，才能找到多项式。您需要 N+1 点才能发现 N 次多项式。这些要点是我们秘密的“分享”。

多项式演示

我们取需要共享的 secret 为 1234，然后取阈值为 3 即至少需要 3 个共享数据才能确定秘密。因此我们要求多项式的阶数为 2。我们需要选择两个随机数作为我们的系数。让我们选择 94 和 166，这给了我们多项式：94x^2 + 166x + 1234。下面是它的样子：

共享数据用多项式上的点来表示，虽然我们的阈值是 3，但我们可以创建任意数量的共享数据。这样可以与任意数量的人分享共享数据，但需要同时拥有 3 个才能确定我们的 secret。例如，让我们通过选择 6 个点来创建 6 个共享数据，如下所示：

如果我们有 3 个这样的共享数据，那么就可以对它们进行插值从而可以找到多项式，进而找到最终的 secret。插值本质上只是找到穿过共享数据表示的点的曲线，如下所示：

多项式的安全漏洞

使用常规多项式存在安全漏洞，如果攻击者有一些点，但不足以满足阈值，则可以使用代数来减少可能的多项式的数量。这使得执行暴力攻击以查找 secret 变得更加容易。在下面的示例中，两个点被盗，攻击者可以尝试每个可能的多项式直到找到 secret，如下所示：

由此可以发现，在有效的密钥共享协议中小于阈值的共享数不应提供有关密钥的任何信息。因此，使用常规多项式将不符合要求。

循环多项式

针对上述的安全漏洞只需要做一个小的改动即可以消除上述安全漏洞 —— 通过应用模数将普通多项式转换为循环多项式（应用模数就是取余数的数学操作），模数应用如下所示：

应用模数会使函数循环，因为它只能达到模数的数量，然后它会再次回到零。这是我们对普通多项式94x^2 + 166x + 1234应用模数 1613 之后函数的样子：

在多普通多项式应用模数的时候有一个需要注意的点：需要确保模数是一个比 Secret、多项式系数以及打算生成的份额数量更大的质数。选择的质数越大，找到 secret 的概率就越低。在上面的例子中选择一个相对较小的 1613，因为它与我们的可视化效果良好。应用模数之后共享数据的点在图形上看起来就是不相关的了：

当共享数据数量达到阈值的时候，仍然可以通过插值找到 secret，但是现在由于应用模数丢失共享数据的部分信息从而低于共享数据数量的阈值并不能提供更多关于 secret 的信息，所以普通多项式存在的安全漏洞也就迎刃而解。

上面这个循环多项式进行 secret 共享的方法也适用于字符串，由于字符串存储为二进制，我们可以将字符串的二进制表示转换为十进制，并将该十进制数作为多项式的 secret。

go 算法实现

Shamir's Secret Share 算法在 Hashicorp Vault 项目中 KEK、Recovery Key 等有非常多的运用，以下是该算法的 go 语言实现：

package shamir

import (
	"crypto/rand"
	"crypto/subtle"
	"fmt"
	mathrand "math/rand"
	"time"

	"github.com/hashicorp/errwrap"
)

const (
	// ShareOverhead is the byte size overhead of each share
	// when using Split on a secret. This is caused by appending
	// a one byte tag to the share.
	ShareOverhead = 1
)

// Tables taken from http://www.samiam.org/galois.html
// They use 0xe5 (229) as the generator
var (
	// logTable provides the log(X)/log(g) at each index X
	logTable = [256]uint8{
		0x00, 0xff, 0xc8, 0x08, 0x91, 0x10, 0xd0, 0x36,
		0x5a, 0x3e, 0xd8, 0x43, 0x99, 0x77, 0xfe, 0x18,
		0x23, 0x20, 0x07, 0x70, 0xa1, 0x6c, 0x0c, 0x7f,
		0x62, 0x8b, 0x40, 0x46, 0xc7, 0x4b, 0xe0, 0x0e,
		0xeb, 0x16, 0xe8, 0xad, 0xcf, 0xcd, 0x39, 0x53,
		0x6a, 0x27, 0x35, 0x93, 0xd4, 0x4e, 0x48, 0xc3,
		0x2b, 0x79, 0x54, 0x28, 0x09, 0x78, 0x0f, 0x21,
		0x90, 0x87, 0x14, 0x2a, 0xa9, 0x9c, 0xd6, 0x74,
		0xb4, 0x7c, 0xde, 0xed, 0xb1, 0x86, 0x76, 0xa4,
		0x98, 0xe2, 0x96, 0x8f, 0x02, 0x32, 0x1c, 0xc1,
		0x33, 0xee, 0xef, 0x81, 0xfd, 0x30, 0x5c, 0x13,
		0x9d, 0x29, 0x17, 0xc4, 0x11, 0x44, 0x8c, 0x80,
		0xf3, 0x73, 0x42, 0x1e, 0x1d, 0xb5, 0xf0, 0x12,
		0xd1, 0x5b, 0x41, 0xa2, 0xd7, 0x2c, 0xe9, 0xd5,
		0x59, 0xcb, 0x50, 0xa8, 0xdc, 0xfc, 0xf2, 0x56,
		0x72, 0xa6, 0x65, 0x2f, 0x9f, 0x9b, 0x3d, 0xba,
		0x7d, 0xc2, 0x45, 0x82, 0xa7, 0x57, 0xb6, 0xa3,
		0x7a, 0x75, 0x4f, 0xae, 0x3f, 0x37, 0x6d, 0x47,
		0x61, 0xbe, 0xab, 0xd3, 0x5f, 0xb0, 0x58, 0xaf,
		0xca, 0x5e, 0xfa, 0x85, 0xe4, 0x4d, 0x8a, 0x05,
		0xfb, 0x60, 0xb7, 0x7b, 0xb8, 0x26, 0x4a, 0x67,
		0xc6, 0x1a, 0xf8, 0x69, 0x25, 0xb3, 0xdb, 0xbd,
		0x66, 0xdd, 0xf1, 0xd2, 0xdf, 0x03, 0x8d, 0x34,
		0xd9, 0x92, 0x0d, 0x63, 0x55, 0xaa, 0x49, 0xec,
		0xbc, 0x95, 0x3c, 0x84, 0x0b, 0xf5, 0xe6, 0xe7,
		0xe5, 0xac, 0x7e, 0x6e, 0xb9, 0xf9, 0xda, 0x8e,
		0x9a, 0xc9, 0x24, 0xe1, 0x0a, 0x15, 0x6b, 0x3a,
		0xa0, 0x51, 0xf4, 0xea, 0xb2, 0x97, 0x9e, 0x5d,
		0x22, 0x88, 0x94, 0xce, 0x19, 0x01, 0x71, 0x4c,
		0xa5, 0xe3, 0xc5, 0x31, 0xbb, 0xcc, 0x1f, 0x2d,
		0x3b, 0x52, 0x6f, 0xf6, 0x2e, 0x89, 0xf7, 0xc0,
		0x68, 0x1b, 0x64, 0x04, 0x06, 0xbf, 0x83, 0x38}

	// expTable provides the anti-log or exponentiation value
	// for the equivalent index
	expTable = [256]uint8{
		0x01, 0xe5, 0x4c, 0xb5, 0xfb, 0x9f, 0xfc, 0x12,
		0x03, 0x34, 0xd4, 0xc4, 0x16, 0xba, 0x1f, 0x36,
		0x05, 0x5c, 0x67, 0x57, 0x3a, 0xd5, 0x21, 0x5a,
		0x0f, 0xe4, 0xa9, 0xf9, 0x4e, 0x64, 0x63, 0xee,
		0x11, 0x37, 0xe0, 0x10, 0xd2, 0xac, 0xa5, 0x29,
		0x33, 0x59, 0x3b, 0x30, 0x6d, 0xef, 0xf4, 0x7b,
		0x55, 0xeb, 0x4d, 0x50, 0xb7, 0x2a, 0x07, 0x8d,
		0xff, 0x26, 0xd7, 0xf0, 0xc2, 0x7e, 0x09, 0x8c,
		0x1a, 0x6a, 0x62, 0x0b, 0x5d, 0x82, 0x1b, 0x8f,
		0x2e, 0xbe, 0xa6, 0x1d, 0xe7, 0x9d, 0x2d, 0x8a,
		0x72, 0xd9, 0xf1, 0x27, 0x32, 0xbc, 0x77, 0x85,
		0x96, 0x70, 0x08, 0x69, 0x56, 0xdf, 0x99, 0x94,
		0xa1, 0x90, 0x18, 0xbb, 0xfa, 0x7a, 0xb0, 0xa7,
		0xf8, 0xab, 0x28, 0xd6, 0x15, 0x8e, 0xcb, 0xf2,
		0x13, 0xe6, 0x78, 0x61, 0x3f, 0x89, 0x46, 0x0d,
		0x35, 0x31, 0x88, 0xa3, 0x41, 0x80, 0xca, 0x17,
		0x5f, 0x53, 0x83, 0xfe, 0xc3, 0x9b, 0x45, 0x39,
		0xe1, 0xf5, 0x9e, 0x19, 0x5e, 0xb6, 0xcf, 0x4b,
		0x38, 0x04, 0xb9, 0x2b, 0xe2, 0xc1, 0x4a, 0xdd,
		0x48, 0x0c, 0xd0, 0x7d, 0x3d, 0x58, 0xde, 0x7c,
		0xd8, 0x14, 0x6b, 0x87, 0x47, 0xe8, 0x79, 0x84,
		0x73, 0x3c, 0xbd, 0x92, 0xc9, 0x23, 0x8b, 0x97,
		0x95, 0x44, 0xdc, 0xad, 0x40, 0x65, 0x86, 0xa2,
		0xa4, 0xcc, 0x7f, 0xec, 0xc0, 0xaf, 0x91, 0xfd,
		0xf7, 0x4f, 0x81, 0x2f, 0x5b, 0xea, 0xa8, 0x1c,
		0x02, 0xd1, 0x98, 0x71, 0xed, 0x25, 0xe3, 0x24,
		0x06, 0x68, 0xb3, 0x93, 0x2c, 0x6f, 0x3e, 0x6c,
		0x0a, 0xb8, 0xce, 0xae, 0x74, 0xb1, 0x42, 0xb4,
		0x1e, 0xd3, 0x49, 0xe9, 0x9c, 0xc8, 0xc6, 0xc7,
		0x22, 0x6e, 0xdb, 0x20, 0xbf, 0x43, 0x51, 0x52,
		0x66, 0xb2, 0x76, 0x60, 0xda, 0xc5, 0xf3, 0xf6,
		0xaa, 0xcd, 0x9a, 0xa0, 0x75, 0x54, 0x0e, 0x01}
)

// polynomial represents a polynomial of arbitrary degree
type polynomial struct {
	coefficients []uint8
}

// makePolynomial constructs a random polynomial of the given
// degree but with the provided intercept value.
func makePolynomial(intercept, degree uint8) (polynomial, error) {
	// Create a wrapper
	p := polynomial{
		coefficients: make([]byte, degree+1),
	}

	// Ensure the intercept is set
	p.coefficients[0] = intercept

	// Assign random co-efficients to the polynomial
	if _, err := rand.Read(p.coefficients[1:]); err != nil {
		return p, err
	}

	return p, nil
}

// evaluate returns the value of the polynomial for the given x
func (p *polynomial) evaluate(x uint8) uint8 {
	// Special case the origin
	if x == 0 {
		return p.coefficients[0]
	}

	// Compute the polynomial value using Horner's method.
	degree := len(p.coefficients) - 1
	out := p.coefficients[degree]
	for i := degree - 1; i >= 0; i-- {
		coeff := p.coefficients[i]
		out = add(mult(out, x), coeff)
	}
	return out
}

// interpolatePolynomial takes N sample points and returns
// the value at a given x using a lagrange interpolation.
func interpolatePolynomial(x_samples, y_samples []uint8, x uint8) uint8 {
	limit := len(x_samples)
	var result, basis uint8
	for i := 0; i < limit; i++ {
		basis = 1
		for j := 0; j < limit; j++ {
			if i == j {
				continue
			}
			num := add(x, x_samples[j])
			denom := add(x_samples[i], x_samples[j])
			term := div(num, denom)
			basis = mult(basis, term)
		}
		group := mult(y_samples[i], basis)
		result = add(result, group)
	}
	return result
}

// div divides two numbers in GF(2^8)
func div(a, b uint8) uint8 {
	if b == 0 {
		// leaks some timing information but we don't care anyways as this
		// should never happen, hence the panic
		panic("divide by zero")
	}

	log_a := logTable[a]
	log_b := logTable[b]
	diff := ((int(log_a) - int(log_b))+255)%255

	ret := int(expTable[diff])

	// Ensure we return zero if a is zero but aren't subject to timing attacks
	ret = subtle.ConstantTimeSelect(subtle.ConstantTimeByteEq(a, 0), 0, ret)
	return uint8(ret)
}

// mult multiplies two numbers in GF(2^8)
func mult(a, b uint8) (out uint8) {
	log_a := logTable[a]
	log_b := logTable[b]
	sum := (int(log_a) + int(log_b)) % 255

	ret := int(expTable[sum])

	// Ensure we return zero if either a or b are zero but aren't subject to
	// timing attacks
	ret = subtle.ConstantTimeSelect(subtle.ConstantTimeByteEq(a, 0), 0, ret)
	ret = subtle.ConstantTimeSelect(subtle.ConstantTimeByteEq(b, 0), 0, ret)

	return uint8(ret)
}

// add combines two numbers in GF(2^8)
// This can also be used for subtraction since it is symmetric.
func add(a, b uint8) uint8 {
	return a ^ b
}

// Split takes an arbitrarily long secret and generates a `parts`
// number of shares, `threshold` of which are required to reconstruct
// the secret. The parts and threshold must be at least 2, and less
// than 256. The returned shares are each one byte longer than the secret
// as they attach a tag used to reconstruct the secret.
func Split(secret []byte, parts, threshold int) ([][]byte, error) {
	// Sanity check the input
	if parts < threshold {
		return nil, fmt.Errorf("parts cannot be less than threshold")
	}
	if parts > 255 {
		return nil, fmt.Errorf("parts cannot exceed 255")
	}
	if threshold < 2 {
		return nil, fmt.Errorf("threshold must be at least 2")
	}
	if threshold > 255 {
		return nil, fmt.Errorf("threshold cannot exceed 255")
	}
	if len(secret) == 0 {
		return nil, fmt.Errorf("cannot split an empty secret")
	}

	// Generate random list of x coordinates
	mathrand.Seed(time.Now().UnixNano())
	xCoordinates := mathrand.Perm(255)

	// Allocate the output array, initialize the final byte
	// of the output with the offset. The representation of each
	// output is {y1, y2, .., yN, x}.
	out := make([][]byte, parts)
	for idx := range out {
		out[idx] = make([]byte, len(secret)+1)
		out[idx][len(secret)] = uint8(xCoordinates[idx]) + 1
	}

	// Construct a random polynomial for each byte of the secret.
	// Because we are using a field of size 256, we can only represent
	// a single byte as the intercept of the polynomial, so we must
	// use a new polynomial for each byte.
	for idx, val := range secret {
		p, err := makePolynomial(val, uint8(threshold-1))
		if err != nil {
			return nil, errwrap.Wrapf("failed to generate polynomial: {{err}}", err)
		}

		// Generate a `parts` number of (x,y) pairs
		// We cheat by encoding the x value once as the final index,
		// so that it only needs to be stored once.
		for i := 0; i < parts; i++ {
			x := uint8(xCoordinates[i]) + 1
			y := p.evaluate(x)
			out[i][idx] = y
		}
	}

	// Return the encoded secrets
	return out, nil
}

// Combine is used to reverse a Split and reconstruct a secret
// once a `threshold` number of parts are available.
func Combine(parts [][]byte) ([]byte, error) {
	// Verify enough parts provided
	if len(parts) < 2 {
		return nil, fmt.Errorf("less than two parts cannot be used to reconstruct the secret")
	}

	// Verify the parts are all the same length
	firstPartLen := len(parts[0])
	if firstPartLen < 2 {
		return nil, fmt.Errorf("parts must be at least two bytes")
	}
	for i := 1; i < len(parts); i++ {
		if len(parts[i]) != firstPartLen {
			return nil, fmt.Errorf("all parts must be the same length")
		}
	}

	// Create a buffer to store the reconstructed secret
	secret := make([]byte, firstPartLen-1)

	// Buffer to store the samples
	x_samples := make([]uint8, len(parts))
	y_samples := make([]uint8, len(parts))

	// Set the x value for each sample and ensure no x_sample values are the same,
	// otherwise div() can be unhappy
	checkMap := map[byte]bool{}
	for i, part := range parts {
		samp := part[firstPartLen-1]
		if exists := checkMap[samp]; exists {
			return nil, fmt.Errorf("duplicate part detected")
		}
		checkMap[samp] = true
		x_samples[i] = samp
	}

	// Reconstruct each byte
	for idx := range secret {
		// Set the y value for each sample
		for i, part := range parts {
			y_samples[i] = part[idx]
		}

		// Interpolate the polynomial and compute the value at 0
		val := interpolatePolynomial(x_samples, y_samples, 0)

		// Evaluate the 0th value to get the intercept
		secret[idx] = val
	}
	return secret, nil
}

References

1. Shamir's Secret Sharing: Explanation and Visualization — Blog — Evervault
2. vault/shamir/shamir.go at main · hashicorp/vault
